Quickly identify the screen 1D/2D code
No plugins, lightning billing
Application scenario is rich
Appearance with ergonomic design
Stable, precise, convenient, practical and efficient
Compatible with a variety of systems
Application Scenarios: Supermarket/convenience store cashiers, customer service desks, ticket ticketing windows, O2O application sites.
Specification
Model Name | UG6200 | |
Read code type | Image | |
1D | Support | |
2D | Support | |
Scan Mobile phone screen | Support | |
Scan computer screen | Support | |
Data transfer Typ | Wireless transmission | |
Interface type | 2.4G Wireless | |
Sensor | CMOS sensor | |
Sight | 624nm red LED | |
Light source | 624nm white LED | |
Scan method | Manual click、automatic、continue | |
Scan angle | Horizontal：40° Perpendicular：30° | |
Voltage | 5V DC±5% | |
Print resolution | ≥30% | |
Test Anti-seismic ability | Falling 1.5m | |
Compatible system | Android / IOS / Windows | |
Scanning speed | 200 Times per second | |
Motion tolerance | 13mil UPC Barcode：30cm/ sec | |
Dimension | 165mm*65mm*92mm | |
Packing dimention | 200mm*98mm*120mm | |
Product weight | 290g | |
Barcode Type |
1D: Code 39 (Code 32), Code 128, UPC/EAN/JAN, Code 93, Interleaved 2 of 5, Codabar, Matrix 2 of 5, Industrial 25(Straight 2 of 5 Industrial) 2D: QR Code, Data Matrix, PDF417 | |
Resolution | 13mil UPC (25-210mm) | 6.7mil PDF417 (25-120mm) |
13mil Code39 (95-160mm) | 10mil PDF417 (25-190mm) | |
5mil Code39 (50-80mm) | 10mil Data Matrix (20-70mm) | |
20mil Code39 (100-310mm） | 20mil QR (30-210mm) | |
Working temperature | -20~+50℃ | |
Storage temperature | -40~+70 | |
Working humidity | 5%~95% | |
