USB Laser 1D Barcode Scanner T-6900



Features

Quickly identify the screen 1D code, appearance with ergonomic design.

Stable, precise, convenient, practical and efficient.

Compatible with a variety of systems.


Specification


Model Name

UG6900

Barcode reading speed

100 times/sec

Identify the lowest contrast

25% of the reflection difference

Reading angle range

±65°, ±70°, ±45° (left, right, forward, backward,

rotation)

Decoding accuracy

0.0762mm (3mil)

Decoding distance

5-680mm (minimum and maximum)

Reading Code System

UPC-A, UPC-E/E1, EAN-13, EAN-8, ISBN/ISSN,

39 yards, 39 yards (ASCII full yard), 32 yards, Trioptic 39 yards, cross 25 yards, industrial 25 yards ( Discrete 2of 5), Matrix 25 yards, Kudaba Code (NW7), 128 yards, UCC/EAN 128, ISBT128,

93 yards, 11 yards (USD-8), MSI/Plessey, UK/Plessey

Light source type

Laser 650nm±10nm

Optical coating finishing

Silver Coating

Interface Type

USB 2.0

Tips

Buzzer sounds

Environmental adaptation parameters

Impact resistance

1.5 meters free fall drop

Operating temperature range

-15°C--45°C

Storage temperature range

-25°C--65°C

Operating Humidity Range

10-92%

Humidity range

10-92%

Ambient light intensity

Max.5,000 Lux (fluorescence)

Physical parameters

Net weight

200g

Gross weight

250g

Main engine size (L*W*H)

163*75*95(mm)

Packing size (L*W*H)

225*106*87(mm)

Electrical parameters



UG6900 3UG6900 4UG6900 2UG6900 5UG6900 6UG6900 7 (2)
