Lighting

white LED

Focusing

red LED

Motion tolerance

2M/S

Reading precision

(> 4MIL)

Scanning angle

Rotation 360°, Tilt 55°, Pitch 55°

Visual Indicator

LED & buzzer

Communication Interface

USB (HID-KBW & Virtual Serial Port)

Supported Bar code

1D:EAN-8,EAN-13,CODE-128,Codabar,UPC-A,UPC-E,

Industrial2of5,EAN-128,Interleave2of5,

Matrix20f5,MSI,GS1Aztec.

2D:QRcode,DataMatrix,PDF417、Azteccode、

MaxicodeAztec.

SIZE

170 mm* 73 mm* 106 mm

Weight

250G( not including the cable)

Visual Indicator

LED,Speaker

Voltage

DC5V±10%

Current

135mA(operating)

Working temperature

-20℃+50℃

Storage temperature

-40℃+70℃

Relative Humidity

5%~95% (Non-condensing)

Electrostatic Protection

4KV (Direct Discharge) 10KV (Air Discharge)

Drop/Shock Resistance

withstands multiple times 1.2 meters drops to concrete

Protection Level

IP54
