Scanning method:

manual or automatic induction

Sensor :

640*480 COMS

Lighting :

white LED

Focusing:

red LED

Motion tolerance :

2M/S

Reading precision:

(> 4MIL)

Scanning angle:

Rotation 360°, Tilt 55°, Pitch 55°

Visual Indicator:

LED & buzzer

1D bar code:

EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleaved 2 of 5

2D bar code :

QR Code, Data Matrix, PDF417, Aztec, Maxicode, Hanxin Code

Communication Interface:

TTL-232 & USB (HID-KBW & Virtual Serial Port)

Battery Specification :

 Lithium Battery

Standby time:

≥5 days

Battery capacity :

2200 mAh

Working current :

170MA

Charging time:

4H

Environmental parameters

Working temperature:

-20℃+50℃

Storage temperature:

-20℃+70℃

Relative Humidity:

5%~95% (Non-condensing)

Ambient illumination:

0-10000 LUX

Electrostatic Protection :

 4KV (Direct Discharge) 10KV (Air Discharge)

Drop/Shock Resistance:

withstands multiple times 1.2 meters drops to concrete

Protection Level :

IP54

Scanner SIZE:

L(164)*W(65)*H(98)MM  Weight :138G( not including the cable)

1Carton(without stand):

57*40*45cm/50pcs/16kgs(box: 18.5*11*8.5cm/1pc/0.35kgs)

1Carton(withstand):

52*43.5*62cm/40pcs/23kgs(box: 21*15*10cm/1pc/0.55kgs)
